Fume hood, shroud, and acoustic ceiling finished with a perimeter trim interface. The shroud maintains a maximum one-eighth-inch clearance relative to the ceiling perimeter. The acoustic ceiling system integrates with the hood assembly per the specified trade divisions. Mechanical layout tags dictate the distribution of gas and vacuum services.
095113 3" PERIMETER TRIM 095113 ACOUSTIC CEILING MAX 1/8" FUME HOOD SHROUD FUME HOOD GAS LAYOUTS LPA VAC LPA VAC BOTTOM L/R-CW, LPA, VAC NOTE : ON MECHANICAL TAG: L/R: ONE SET PER SIDE S: SPLIT EQUALLY PER SIDE AT ADA HOODS PROVIDE ADA COMPLIANT FITTINGS REFER TO FLOOR PLANS FOR SERVICES EX: 1/2" = 1'-0" 4 FUME HOODS
