A double check valve assembly is housed within an Oldcastle precast concrete vault featuring locking steel doors flush with the finish grade. The internal piping utilizes PVC Schedule 80 fittings and includes a pressure reducing valve and typical pressure gauges oriented with test cocks upright for easy access. The vault rests on a bed of compacted five-eighths inch crushed rock with one-third cubic yard of drain rock placed at both ends where weep hole slots discharge. A one-inch PVC Schedule 40 weep hole slot drain provides drainage to rock pockets on both sides of the vault.
6"MIN CLEAR 12"CLR. 1. PRESSURE REDUCING VALVE 2. PRESSURE GAUGE, TYP. 3. DOUBLE CHECK VALVE ASSEMBLY 4. TEST COCKS UPRIGHT FOR EASY ACCESS 5. PVC SCH80 FITTINGS, TYP. 6. OLDCASTLE #TA25 CONCRETE VAULT WITH LOCKING STEEL DOORS 7. 1" PVC SCH40 WEEK HOLE SLOT DRAIN TO ROCK POCKET BOTH SIDES OF VAULT 8. COMPACTED 5/8" CRUSHED ROCK 9. 1/3CU. YARD DRAIN ROCK AT BOTH ENDS OF VAULT WHERE WEEP HOLE DISCHARGES 6" MIN. 1 2 4 3 5 8 7 9 6
