The sign is constructed of aluminum with a non-glare finish, featuring a white accessibility symbol and directional arrow on a blue background. The square sign measures 18 inches by 18 inches. Mounting height is specified as 6 feet 8 inches above the adjacent surface in paths of travel, or 5 feet 0 inches above ground in landscape areas.
SYMBOL WITH RIGHT ARROW SYMBOL WITH LEFT ARROW 18" 18" NOTES: 1. SIGN SHALL BE ALUMINUM WITH NON-GLARE FINISH, WHITE SYMBOL ON BLUE BACKGROUND. 2. SIGN SHALL BE MOUNTED ON SIGN POST PER DETAIL 12, THIS SHEET. 3. BOTTOM OF SIGN SHALL BE 6'-8" ABOVE ADJACENT SURFACE IF IN THE PATH OF TRAVEL OR 5'-0" ABOVE GROUND IN LANDSCAPE AREA .
