The vacuum pump and receiver tank rest on a steel base supported by vibration isolation pads over a concrete housekeeping pad. Piping from the system includes a 2-inch line equipped with a typical shutoff valve, typical flexible connector, and typical union. A liquid separator connects to the receiver drain line, routing through an automatic drain valve to a floor sink with a 1-inch drain line. Exhaust or vent lines terminate at the exterior wall with a bug screen.
TERMINATE WITH BUG SCREEN EXTERIOR WALL 2" LV FROM SYSTEM FLEX CONNECTOR (TYP) LIQUID SEPARATOR TO FLOOR SINK 1" D FINISHED FLOOR FLOOR SINK RECEIVER DRAIN LINE HOUSEKEEPING PAD VIBRATION ISOLATION (TYP) STEEL BASE 2" LV 2" LV 2" LV 1 UNION (TYP) SHUTOFF VALVE (TYP) NO ROOF RECEIVER VACUUM PUMP 1. AUTOMATIC DRAIN VALVE TO FLOOR SINK. NOTES: 2
