L-YCGPS — Roof Level

Landscape · L-YCGPS

Roof Level

Units: imperial
Sheet: LO-S1.2.1
Discipline: Landscape

Materials

Steel Timber / Wood

Elements

Beams Columns Connections / Plates Roofs

Connections

Beam-to-Column Bolted Connection Timber / Mass-Timber Connection

Text on the drawing

THRU CONNECTION PL “tp” & BOLTS SEE SCHED SIM 1 3/4" TYP 3" TYP 1 3/4" 2 1/4" MAX 1/2" CAP PL PER 3" Wx PER PLAN, TYP COL PER PLAN SLOT FOR PL'S, TYP ROOF LEVEL DEEPER PL TO BE CONTINUOUS TAPER AS SHOWN IF BM DEPTHS VARIES GL ROOF LEVEL 11 LO S1.2.1 / 9 LO S1.2.1 / 12 LO S1.2.2
