An irrigation drip zone kit model ICZ-101-LF with filter tipped at forty-five degrees and a twenty-five PSI regulator is housed within a jumbo valve box set below finish grade. The assembly connects to main line pipe and fittings using Schedule 80 threaded on each end nipples and typical PVC unions. Two waterproof connectors join eighteen to twenty-four inch coiled wires. The valve box rests on four brick supports over a base of three-quarters inch minus washed gravel.
18-24" COILED WIRE WATERPROOF CONNECTORS (2) JUMBO VALVE BOX DRIP ZONE KIT MODEL ICZ-101-LF WITH FILTER (TIP 45 DEGREES) 25 PSI REGULATOR SCH 80 T.O.E. NIPPLE(2) MAIN LINE PIPE & FITTINGS BRICK SUPPORTS (4) 3/4" MINUS WASHED GRAVEL FINISH GRADE PVC UNION, TYP.
