A ten-inch round bolt-down box set to grade houses a six-inch polyvinyl chloride schedule 40 pipe sleeve below grade. A gate valve with a resilient wedge non-rising stem connects to the main water supply line. The assembly maintains an eighteen to thirty-inch clearance from finish grade to the pipe.
