Wood joists bear against subpurlins secured with an "F" hanger and sixteen-penny nails with quantities specified by the manufacturer. Subpurlins consist of two-by-six Number two or better Douglas fir, with two-by-eight or three-by-six members used where required by plans or details. Wood nailers support the roof sheathing above. Bridging is provided as detailed by the joist manufacturer.
2x6 No. 2 SUBPURLIN OR BETTER D.F., TYP. USE 2x8 OR 3x6 WHERE REQUIRED BY PLANS OR DETAILS 16d (QUANTITY BY MFR.) BRIDGING (BY JOIST MFR.) "F" HANGER SHEATHING WOOD NAILER JOIST
