This landscape irrigation detail shows a pop-up spray sprinkler positioned flush with finish grade and the top of the mulch layer. The sprinkler connects through a triple swing joint to a Schedule 40 PVC tee mounted on the lateral line. Installation notes specify using the bottom inlet only on all pop-up spray heads.
1. FINISH GRADE 2. POP-UP ROTOR 3. MULCH 4. PLANTING SOIL/ROOT ZONE MIX 5. TRIPLE SWING JOINT 6. LATERAL LINE 7. SCH. 40 PVC TEE FLUSH 1. FINISH GRADE/TOP OF MULCH 2. POP-UP SPRAY SPRINKLER 3. TRIPLE SWING JOINT 4. SCH. 40 PVC TEE 5. LATERAL LINE NOTES: A. USE BOTTOM INLET ONLY ON ALL POP-UP SPRAY HEADS. 1 2 3 4 5
