Stone paving type three is installed with typical four-inch joints aligned across adjacent units as indicated. Standard joint spacing is maintained throughout the modular grid pattern.
JOINT, TYP. 4" TYP. ALIGN ALIGN STONE PAVING TYPE 3, SEE PAVING PLAN 4" TYP. REF: L8-300 1/2" = 1'-0" 12 STONE SETTS PAVING, TYP.
