L-XTJ5B — Wall Panel To Ext Jamb

Landscape · L-XTJ5B

Wall Panel To Ext Jamb

Scale: 3" = 1'-0"
Units: imperial
Sheet: LO-A9.6.1
Discipline: Landscape

Materials

Aluminum Composite Glass / Glazing Metal (misc.)

Elements

Connections / Plates Facades / Cladding Insulation Walls Waterproofing / Flashing Windows

Text on the drawing

HEAD MULLION PROFILE AS SPECIFIED 1" INSULATED GLAZING UNIT AS SPECIFIED ALUMINUM PANEL WITH CLEAT ATTACHMENT TO THERMALLY IMPROVED SUBFRAME CONTINUOS EXTERIOR INSULATION BREAK METAL TRIM METAL TRIM OVER EXPOSED AIR/MOISTURE BARRIER WPC-1 WALL PANEL ALUMINUM Z-CLIP PANEL SYSTEM

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
