A pop-up spray head connects to a Schedule 40 polyvinyl chloride lateral line with a threaded outlet, a half-inch barbed elbow, a half-inch Marlex street elbow, and a length of linear low-density polyethylene pipe measuring fourteen inches minimum to twenty-four inches maximum. Compacted soil surrounds the head and flex pipe up to the finish grade.
FINISH GRADE COMPACTED SOIL AROUND HEAD AND FLEX PIPE POP-UP SPRAY HEAD 1/2" MARLEX STREET ELL 1/2" BARBED ELL 12" 1/2" BARBED ELL LINEAR LOW DENSITY POLYETHYLENE PIPE 14" LONG MINIMUM 24" LONG MAXIMUM PVC LATERAL LINE SCH. 40 PVC W/ 1/2" THREADED OUTLET
