A one-quarter inch diameter safety rail is positioned at the front and back of shelves at island bench conditions, and along all four sides of heavy-duty shelving. Rods require a tight fit with no caulking required. Edge clearances measure three-eighths of an inch and one inch at spacing intervals.
1/4"ø SAFETY RAIL AT FRONT 3/8" -PROVIDE AT FRONT & BACK OF SHELF AT ISLAND BENCH CONDITION. 1" PROVIDE AT ALL (4) SIDES AT HEAVY DUTY SHELVING. SAFETY ROD ELEVATION NTS 3/8" 3/8" 1" ROD TO BE TIGHT FIT NO CAULKING REQUIRED.
