Landscape Details Sheet with Trellis, Light Fixture, and Platform

Elements

About this detail

Architectural landscape details comprising a trellis structure, a flush light fixture at a tree planting footing, and a platform at a common area. The trellis detail includes framing and connection notes. The light fixture detail features a prefabricated pergola aluminum post with a post base connection set into a concrete paving and pole foundation with smooth slip dowels. The platform detail includes plan and section views with concrete walls, stairs, bands, flush curbs, turf over grasspave, and concrete slab on grade.
