A one-inch diameter pipe serves as the gate post with a quarter-inch by four-inch by four-inch plate welded to the pipe and the corrugated metal gate frame. An eight-inch long rod is welded to the top pipe sleeve and set into the bottom sleeve adjacent to the concrete masonry unit block wall.
3" 12" 1 CMU BLOCK WALL 2 3 4 5 CORRUGATED METAL GATE 03 2-L5.02 1 3 GATE POST 1" DIA. PIPE WITH 1/4"x4"x4" PLATE WELDED TO PIPE AND GATE FRAME 01/02 - 8" LONG ROD WELDED TO TOP PIPE SLEEVE AND SET IN BOTTOM SLEEVE 01/02 -
