L-X6PVS — Glulam Beam To Glulam Girder With Concealed Connection

Landscape · L-X6PVS

Glulam Beam To Glulam Girder With Concealed Connection

Units: imperial
Sheet: LO-S1.6.1
Discipline: Landscape

Materials

Elements

Beams Connections / Plates Roofs

Connections

Beam-to-Beam Timber / Mass-Timber Connection

Text on the drawing

ROOF GLULAM GIRDER PER PLAN GLULAM BEAM PER PLAN CLT PANEL, ORIENTATION MAY VARY CLT PANEL WHERE OCCURS SIMPSON HANGER PER PLAN GLULAM BEAM WHERE OCCURS CLT ATTACHMENT TO GLULAM BEAM PER / 8 LO S1.6.1 (3) SIMPSON SDWC15600 SCREWS w/ (1" MIN SPACING, 1/2" MIN EDGE DISTANCE) 2" NTS 2
