Landscape · L-X44TG

1-Hr/2-Hr Insulated Pipe Penetration

Units: imperial
Sheet: LO-A9.6.2
Discipline: Landscape

Materials

Gypsum / Drywall

Elements

Insulation Roof / Floor Openings Walls

Text on the drawing

A ELEVATION ANNULAR SPACE SHALL BE 0" MIN. TO 1 7/8" MAX. UL LISTING: W-L-5029 B B LINE OF SEALANT BEAD

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
