Steel landscape edging consists of one-eighth inch thick by four-inch wide by sixteen-foot long steel sections secured by tapered steel stakes spaced at five stakes per sixteen-foot section on the exterior side of the gravel mulch area. The gravel mulch side is maintained one-half inch below the top of the edging with compacted material along the edge. On the exterior side, compacted soil is positioned one and one-quarter inches below the top of the edging, while bark mulch is maintained one inch below the top of the edging. Installation must be completed in accordance with manufacturer specifications using Sure-Loc edging or approved equal.
STEEL LANDSCAPE EDGING TAPERED STEEL STAKES ON EXTERIOR SIDE OF GRAVEL MULCH AREA 5 STAKES PER 16' SECTION GRAVEL MULCH SIDE 1 /2" BELOW TOP OF EDGING. COMPACT ALONG EDGING STEEL EDGING EXTERIOR SIDE: SOIL TO BE 1 /4" BELOW TOP OF EDGING COMPACTED. BARK MULCH TO BE 1" BELOW TOP OF EDGING 1. INSTALLATION TO BE COMPLETED IN ACCORDANCE WITH MANUFACTURER'S SPECIFICATIONS. NOTES: 2. STEEL EDGING TO BE 1 /8" THICKNESS X 4" X 16' 3. EDGING TO BE 'SURE LOC' 800-787-3562 OR APPROVED EQUAL. www.surelocedging.com
