Text on the drawing
MAX POINT LOAD 4" MIN TYPICAL STUDS SEE 400T200-68 x 16" LONG (MIN) @ POINT LOAD LOCATION #10 SMS @ 4"OC ES NOTE: MAXIMUM POINT LOAD = 800#. / 2 LO S1.4.1 CONT BOTT TRACK CONC SLAB TO MATCH TRACK WIDTH
