L-WKZ44 — Conduit Sleeve Floor Fire Penetration Detail

Landscape · L-WKZ44

Conduit Sleeve Floor Fire Penetration Detail

Units: imperial
Sheet: LO-T2.0.3
Discipline: Landscape

Materials

Elements

Anchors / Embeds Floors / Slabs Roof / Floor Openings

Connections

Base Plate / Anchorage

Text on the drawing

SECTION A A 4" ID RGS CONDUIT FIRESTOP MATERIAL 5" ID RGS SLEEVE FIRESTOP MATERIAL 5" ID RGS SLEEVE TYP. FOUR CONCRETE ANCHORS FINISHED CONCRETE FLOOR SLAB 1" ABOVE SLAB 4" ID RGS CONDUIT
