An underground irrigation line is bedded in a three-inch minimum depth of washed gravel with brick supports placed beneath the valve boxes and reducers. A master valve is installed with unions on each side for threaded models, accompanied by control wires and a two-wire system decoder fastened to the box with a bracket. A flow sensor is integrated into the pipe run maintaining specified downstream and upstream straight pipe distances of five times and ten times the pipe diameter. Communication cables include a three-foot coiled length and splices executed according to the manufacturer's recommendation inside standard size valve boxes set below the landscape surface.
5X DIAMETER OF PIPE 10X DIAMETER OF PIPE FLOW → LANDSCAPE SURFACE CONCENTRIC REDUCER (WHERE REQUIRED FOR TRANSITION BETWEEN PIPE SIZES) BRICK (4 PER BOX) CONCENTRIC REDUCER (WHERE REQUIRED FOR TRANSITION BETWEEN PIPE SIZES) CONTROL WIRE. MASTER VALVE - INSTALL UNIONS ON EACH SIDE (THREADED MODELS) 3" MIN. DEPTH WASHED GRAVEL BRICK (4 PER BOX) 3" MIN. DEPTH WASHED GRAVEL STANDARD SIZE VALVE BOX LANDSCAPE SURFACE COMMUNICATION CABLE SPLICE PER MANUFACTURER'S RECOMMENDATION FLOW SENSOR 3' LENGTH OF COILED COMMUNICATION CABLE TWO WIRE SYSTEM: FASTEN DECODER TO BOX WITH BRACKET
