Clean backfill compacted to ninety percent sits above a layer of bedding material that surrounds the conduits. A minimum separation of two inches is maintained between adjacent pipes. Wiring is run beneath and beside the mainline, taped and bundled at ten-foot intervals. All solvent weld plastic piping is snaked in the trench, and a twenty-four-inch loop is tied in all wiring at directional changes of thirty degrees or greater before being untied after connections.
SECTION VIEW PLAN VIEW NOTES: MAINLINE, LATERAL, AND WIRING IN THE SAME TRENCH MAINLINE PIPE LATERAL PIPE PIPE AND WIRE SLEEVING WIRE W/O CONDUIT PROVIDE A MINIMUM OF 2" BETWEEN PIPES RUN WIRE BENEATH AND BESIDE MAINLINE. TAPE AND BUNDLE AT 10-FOOT INTERVALS. ALL SOLVENT WELD PLASTIC PIPING TO BE SNAKED IN TRENCH AS SHOWN TIE A 24" LOOP IN ALL WIRING AT CHANGES IN DIRECTION OF 30° OR GREATER. UNTIE AFTER ALL CONNECTIONS HAVE BEEN MADE. 4" 4" 4" 4" 4" 4" 4" BEDDING MATERIAL CLEAN BACKFILL - 90% COMPACTION REQUIRED
