L-W94SF — Reduced Pressure Backflow Assembly Detail

Landscape · L-W94SF

Reduced Pressure Backflow Assembly Detail

Units: imperial
Sheet: LO-P5.0.1
Discipline: Landscape

Materials

Elements

Drainage Floors / Slabs

Text on the drawing

STRAINER DOMESTIC COLD WATER SUPPLY FUNNEL TO INDIRECT WASTE RECEPTOR FLOOR 1. 12" MINIMUM. REFER TO LOCAL CODES / AHJ. 2. REFER TO FLOOR PLANS FOR PIPE SIZES. NOTES: 1 NON-POTABLE WATER PRESSURE GAUGE SHUTOFF VALVE (TYP) RPBA 2 2 NONE 4 REDUCED PRESSURE BACKFLOW ASSEMBLY DETAIL
