Unistrut P9002 telescoping strut is suspended at forty-eight inches on center maximum using Unistrut P1000SL channels secured to the overhead structure. Unistrut P2458-18 tubular knee braces provide lateral support, connected with Unistrut P1325 ninety-degree angle fittings at each corner. The assembly accommodates ductwork and building services, with finished ceiling and trim plates installed per division nine where applicable.
REFER TO ARCHITECTURALS SECTION FINISHED CEILING AND TRIM PLATE (WHERE OCCURS BY DIV. 9) UNISTRUT P9002 TELESCOPING STRUT 48" ON CENTER MAXIMUM UNISTRUT P2458-18 TUBULAR KNEE BRACE SUPPORTS UNISTRUT P1325 90° ANGLE FITTING UNISTRUT P1325 90° ANGLE FITTING AT EACH CORNER. SECURE TO HORIZONTAL STRUCTURE MOUNTED UNISTRUT UNISTRUT P1000 SECURED TO HORIZONTAL STRUCTURE MOUNTED UNISTRUT. UNISTRUT P1000SL SECURED TO STRUCTURE ABOVE NOTE: COORDINATE LOCATION OF ALL UPRIGHTS AND DIAGONAL BRACING WITH ALL PIPIING, DUCTWORK AND LIGHTING, ETC... BOX AROUND DUCTWORK OR OTHER OBSTRUCTION UNISTRUT P1000SL
