Basketball court striping layout featuring white pavement markings two inches wide and eight inches deep typically, with a post footing eighteen inches in diameter installed per manufacturer recommendations. The layout provides a fifty-foot optimum width with nineteen-foot nine-inch key dimensions and a six-foot radius arc. Ten feet of unobstructed space is preferable with a three-foot minimum.
50' OPTIMUM 5'-3" 4' 19'9" 19'9" 10' UNOBSTRUCTED SPACE PREFERABLE - 3' MIN 7' 1' 3' TYP. 15" R6' 6' 6' VERIFY POST FOOTING INSTALLED PER MANUF. RECOMMENDATIONS SEC 12 93 00.13 18"Ø 2" WIDE 8" DEEP TYP. NOTES: 1. PAVEMENT MARKINGS TO BE WHITE (SEC 32 17 23.13)
