L-VVREK — Ssew - Shower Pipe Support

Landscape · L-VVREK

Ssew - Shower Pipe Support

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: LO-LF4.1.6
Discipline: Landscape

Materials

Stainless Steel Steel

Elements

Bracing Connections / Plates Walls

Connections

Bracing Connection

Text on the drawing

STAINLESS STEEL ESCUTCHEON. SHOWER HEAD BRUSHED STAINLESS STEEL SUPPORT BRACE STAINLESS STEEL 1" IPS PIPE CLAMP ℄ STAINLESS STEEL PIPE NIPPLE AND ELBOW PROVIDE STRUCTURAL BACKING IN WALL. NOTE: BRACKET CAN BE MOUNTED BELOW OR ABOVE SHOWER. VIEW : A-A A A STAINLESS STEEL WALL FLANGE 36" 25" 60.00° 1 9/16" 8'-0" A.F.F. 82" A.F.F. MIN. CLEAR - 96" A.F.F. MAX. 120.00° 2 1/16" .
