Precast Concrete Liner Paver Sand Set

Materials

About this detail

A sand-set precast concrete paver assembly bears on a four-inch sand bedding course. Below the bedding course lies a four-inch layer of AASHTO number 8 graded base, followed by a six-inch layer of AASHTO number 57 graded subbase. A geotextile fabric separates the subbase from the underlying compacted subgrade. The surface consists of four-inch by three-inch by twelve-inch charcoal color plank pavers by Mutual Materials with hand-tight joints swept with polymeric sand.
