A five-foot long by four-foot wide by ten-inch high granite curb rests upon a seven-inch compacted aggregate base and a three-inch compacted subgrade. An expansion joint separates the granite curb from a ten-inch concrete gutter detailed on civil drawings, which abuts an asphalt surface. On the opposite side, cast-in-place concrete paving ties into the curb assembly over the compacted aggregate base.
3a L9.01 Granite Curb, 5'(L) x 4'(W) x 10"(H) 7" Compacted Aggregate Base, See Civil Drawings 3" Compacted Subgrade Asphalt, See Civil Drawings Expansion Joint 4'-0" 10" Concrete Gutter, See Civil Drawings 1 L9.01 C.I.P Concrete Paving
