The drawing shows a cold-formed steel header assembly comprising a bottom track and a 600S162-54 stud connected to a vertical wall stud. Fasteners secure the members together with a specified gap or clearance notation. Text notes indicate requirements for track installation and full-length components.
Text on the drawing
W < 4'-0" 600S162-54 STUD BOTTOM TRACK WALL STUD (1/16) EA SIDE TRACK PER SCHED, T&B FULL LENGTH NO SPLICE A SINGLE STUD HEADER
