This landscape plan details a central sculpture installation surrounded by a seven-foot-eight-inch diameter circular bed of one-to-two-inch river rock and boulder accents. Boulder size and placement are confirmed in the field by the landscape architect. The surrounding hardscape consists of cast-in-place concrete paving with aligned control joints and integrated recessed lighting along the perimeter. The installation is dimensioned and aligned relative to the property line and adjacent paving joints.
Ø 7'-8" Property Line Recessed Light, See Lighting Drawings Boulder Size and Placement to be Confirmed in Field by Landscape Architect Sculpture by Others 2 L9.02 1 L9.01 C.I.P Concrete Paving 1-2" River Rock 4" 4" 4" 2'-3" Align Align 3 L9.02 4" Recessed Light, See Lighting Drawings Property Line
