A square cast-in-place concrete collar surrounds a one-foot diameter cleanout lid and frame for a plaza deck drain below. The concrete collar features a six-inch width extending outward from the edge of the lid in plan view. The section view shows the collar set at approximately four inches in depth relative to the finished floor elevation of the installed plant area.
FFE OF PLANT AREA INSTALLED ~ 4" CIP CONCRETE COLLAR, 6" WIDTH CLEAN OUT LID AND FRAME FOR PLAZA DECK DRAIN BELOW, SEE PLUMBING 1' DIA. CLEAN OUT LID FOR PLAZA DECK DRAIN BELOW, SEE PLUMBING SQUARE CIP CONCRETE COLLAR, 6" WIDTH FROM EDGE OF LID PLAN VIEW SECTION LANDSCAPE AREA 6" 6" 1' - 0" DIA. 6" 6" 6" 6"
