L-TTYFC — Brace Parallel To Deck Flutes

Landscape · L-TTYFC

Brace Parallel To Deck Flutes

Units: imperial
Sheet: LO-S1.4.4
Discipline: Landscape

Materials

Glass / Glazing Steel

Elements

Anchors / Embeds Bracing Connections / Plates Decks

Connections

Bolted Connection Bracing Connection Deck Attachment Embed Plate

Text on the drawing

(6) 3/8"ø HILTI KWIK BOLT TZ (MIN EMBED 2") CENTER ANCHORS PLATE TO LOWER DECK FLUTES 4" 7" 7" F -
