An epoxy resin cup sink is recessed into a dished construction fume hood work surface and secured with epoxy resin adhesive. The rim features a one-quarter-inch continuous raised edge matching the surrounding counter profile. The sink extends eight inches vertically to the centerline connection, with an overall depth dimensioned below.
EPOXY RESIN CUP SINK DISHED CONSTRUCTION FUME HOOD WORK SURFACE EPOXY RESIN ADHESIVE 1/4 " CONTINUOUS RAISED EDGE CL OF CUPSINK 0' - 3" 0' - 0 1/4" 0' - 1 1/2" 0' - 8"
