An inline master valve and flow meter are installed within separate rectangular valve boxes set atop eight inches of pea gravel. The piping layout requires a minimum upstream distance of ten times the flow meter size and a minimum downstream distance of five times the flow meter size. Waterproof electrical connectors join the control wiring to the controller, explicitly prohibiting pre-filled type connectors. Color-coded wire connections include black, red, white, and blue leads tied back to a black wire harness.
MIN UPSTREAM DISTANCE 10 x FLOW METER SIZE 8" OF PEA GRAVEL IN VALVE BOXES FLOW METER WATERPROOF ELECTRICAL CONNECTORS (DO NOT USE PRE-FILLED TYPE CONNECTORS) MIN DOWNSTREAM DISTANCE 5 x FLOW METER SIZE RECTANGULAR VALVE BOX BLACK RED CONTROLLER BLACK WIRE HARNESS WHITE BLUE MASTER VALVE
