The assembly illustrates a flexible duct connected to a supply branch equipped with a volume damper, terminating at a diffuser set within a ceiling system. The components are labeled with standard mechanical ventilation callouts, demonstrating the pathway from the supply branch to the conditioned space through the ceiling.
Text on the drawing
VOLUME DAMPER FLEX DUCT SUPPLY BRANCH CEILING 1
