Cast-in-place concrete paving is reinforced with number four bars at sixteen inches on center and features a sand-blasted finish. The concrete slab rests on a compacted aggregate base built to city standards. The base layer is supported by compacted fill or undisturbed subgrade per city standard. Finish grade is established per grading plans.
PER CITY STANDARD PER CITY STANDARD FINISH GRADE SEE GRADING PLANS CAST IN PLACE CONCRETE PAVING WITH REINFORCING (#4 @ 16" O.C.); SAND-BLASTED FINISH, TYP COMPACTED AGGREGATE BASE PER CITY STANDARD COMPACTED FILL OR UNDISTURBED SUBGRADE 3 - 2 -
