Point of connection details indicate a recycled cold water service and a domestic cold water service with sizes and loads to be determined. Both service lines reference civil utility plans for continuation and the location of the backflow preventer. An additional reference note instructs to refer to civil utility plans for continuation.
P.O.C SERVICE: DOMESTIC COLD WATER SIZE: TO BE DETERMINED LOAD: TO BE DETERMINED SEE CIVIL UTILITY PLANS FOR CONT. AND LOCATION OF BACKFLOW PREVENTER. FOR REFERENCE ONLY. REFER TO CIVIL UTILITY PLANS FOR CONT. P.O.C SERVICE: RECYCLED COLD WATER SIZE: TO BE DETERMINED LOAD: TO BE DETERMINED SEE CIVIL UTILITY PLANS FOR CONT. AND LOCATION OF BACKFLOW PREVENTER.
