A structural slab supports a waterproofing and drainage layer detailed per architectural drawings. Horticulture soil and a six-inch layer of top soil finish the top of the assembly.
Structural Slab, Waterproofing and Drainage, See Architectural Drawings Horticulture Soil Top Soil 6"
