L-RHV2K — Typical Upper Cabinet

Landscape · L-RHV2K

Typical Upper Cabinet

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: LO-A9.7.1
Discipline: Landscape

Materials

Composite Metal (misc.)Timber / Wood

Elements

Millwork / Casework

Text on the drawing

PIN AND GROMMET HOLES, TYP. COUNTER-SINK ALL FASTENING DEVICES, TYPICAL 3/4" WPC-1 CABINET FACES T.O. CABINET REF. INT. ELEV @ 8' - 0" B.O. CABINET REF. INT. ELEV @ 4' - 6" 3/4" MP-1 ADJUSTABLE CABINET INTERIOR SHELVES CONCEALED HINGE EXTEND END PANEL @ END OF ROW WHERE NOT AGAINST ANOTHER SURFACE, TYP. VERTICAL PULL 3/4" MP-1 CABINET BOTTOM 2" 3/4" MP-1 CABINET BACK PANEL 1" WPC-1 CABINET TOP
