Cast-in-place concrete paving surrounds a 7'-8" diameter area filled with one to two-inch river rock and boulders. A sculpture installed by others sits within the rock field, with boulder size and placement confirmed in the field by the landscape architect. Recessed lights are integrated along the property line and paving edges. Dimensions and alignments establish the layout relative to the property line.
Ø 7'-8" Property Line Recessed Light, See Lighting Drawings Boulder Size and Placement to be Confirmed in Field by Landscape Architect Sculpture by Others 2 L9.02 1 L9.01 C.I.P Concrete Paving 1-2" River Rock 4" 4" 4" 2'-3" Align Align 3 L9.02 4" Recessed Light, See Lighting Drawings Property Line
