An electric remote control valve and a brass or bronze angle gate valve are housed inside a specified vault set flush with the finished grade, resting on paving bricks over a six-inch deep pea gravel sump. The assembly connects to a Schedule 40 PVC main line buried a minimum of 18 inches deep and a Class 200 PVC lateral line buried a minimum of 12 inches deep using Schedule 80 PVC threaded nipples, unions, standard elbows, and a threaded-one-end nipple. Control wires feature a 24-inch coiled section inside the vault with an extra colored coil installed per valve box, and are taped to the side of the main line at 10 feet on center. A valve box extension is added as required.
24" COILED WIRE SPECIFIED VAULT FLUSH WITH FINISHED GRADE ELECTRIC REMOTE CONTROL VALVE CL 200 PVC LATERAL 12" DEEP MIN. 24" COILED EXTRA WIRE (DIFFERENT COLOR) INSTALL ONE EXTRA COIL PER VALVE BOX 6" DEEP PEA GRAVEL SUMP TAPE WIRE TO SIDE OF MAIN LINE AT 10'-0" O.C. SCH 80 PVC UNION BRASS/BRONZE ANGLE GATE VALVE RED/WHITE OR EQUAL FINISH GRADE SCH 80 PVC THREADED NIPPLE SCH 80 ST90 VALVE BOX EXTENSION AS REQUIRED SCH 80 PVC SS T.O.E. NIPPLE PAVING BRICK SCH 40 PVC MAIN 18" DEEP MIN.
