Landscape · L-QH62M

Pedestrian Concrete at Mat Slab

Materials

Concrete

Elements

Floors / Slabs Foundations / Footings Expansion / Control Joints Waterproofing / Flashing

Connections

Expansion / Slip Connection

About this detail

A five-inch thick pedestrian concrete topping is placed over a mat slab with a medium broom finish unless noted otherwise on plans. Waterproofing and a drainboard are installed between the topping and the mat slab. Expansion joints are provided a maximum of eighteen inches on center in both directions and adjacent to buildings, walls, and other vertical elements. Score joints and expansion joints are placed as shown on the plan, with a three-inch clearance noted.
