The detail illustrates an epoxy resin sink mounted into a countertop utilizing epoxy resin adhesive for the joint. The cross-section highlights the sink basin, an internal epoxy resin overflow, sink stopper, and an outlet piece connected at the bottom drain. Dimension references direct the user to the architectural plans and sink schedule for exact sizing.
EPOXY RESIN SINK (REFER TO SINK SCHEDULE FOR SINK DIMENSIONS) EPOXY RESIN ADHESIVE EPOXY RESIN OVERFLOW, SINK STOPPER AND OUTLET PIECE BY DIV. 11 REFER TO PLANS FOR ACTUAL SIZE REFER TO PLANS FOR ACTUAL SIZE PLAN SECTION
