L-QASW6 — Pipe Support Hanger

Landscape · L-QASW6

Pipe Support Hanger

Units: imperial
Sheet: LO-P5.0.3
Discipline: Landscape

Materials

Elements

Connections / Plates Insulation Waterproofing / Flashing

Text on the drawing

PIPE INSULATED PIPE WITH VAPOR BARRIER INSULATION 1 2 3 UNINSULATED PIPE HANGER ROD PIPE INSULATION HANGER ROD PIPE HANGER ROD A. REFER TO SPECIFICATION 22 07 00 FOR INSULATION GENERAL NOTES: 1 1 3
