A rotor pop-up sprinkler connects to a PVC lateral line through an adjustable pre-fabricated double swing joint assembly with a minimum length of twelve inches. The swing joint assembly angles shall not exceed forty-five degrees to ensure proper flexibility and prevent shear stress on the lateral line. The sprinkler body is set flush with the finish grade surrounded by compacted soil, maintaining a minimum depth of twelve inches from the lateral line to the surface.
PVC LATERAL LINE ADJUSTABLE PRE-FABRICATED DOUBLE SWING JOINT ASSEMBLY, 12" MIN. LENGTH. COMPACTED SOIL FINISH GRADE ROTOR POP-UP SPRINKLER ADJUSTABLE PRE-FABRICATED DOUBLE SWING JOINT ASSEMBLY, 12" MIN. LENGTH. (ANGLE SHALL NOT EXCEED 45 DEGREES). SIDE VIEW 12" PVC LATERAL LINE
