Pedestrian concrete paving transitions to a three-inch deep mulch bed over top of subgrade. Planting areas are located per plans, transitioning at finish grade over the sloped subgrade. A two-foot transition zone spans between the concrete edge and the full mulch depth.
PEDESTRIAN CONCRETE PAVING, SCD 2'-0" 1 2 " 1" MULCH, SEE SPECS FINISH GRADE TOP OF SUBGRADE PLANTING, SEE PLANS 3"
