L-PM6XB — Mechanical Screen At Offset Detail

Landscape · L-PM6XB

Mechanical Screen At Offset Detail

Scale: 3/8" = 1'-0"
Units: imperial
Sheet: LO-S6.0.2
Discipline: Landscape

Materials

Elements

Partitions Walls

Connections

Text on the drawing

HSS5X3X3/16 HSS4X4X3/16 HSS3X3X1/8 HSS3X3X1X8 TYP CONT CONT LO S6.0.2 4 LO S6.0.2 3 TYP AT OFFSET SCREEN HSS3X3X1/8 1 1 MIN 12" 3/8" = 1'-0" 1
