An irrigation ring composed of in-line emitter tubing forms a four-foot diameter circle delivering water via two emitters per tree at a rate of one-half gallon per minute. The system utilizes flexible polyvinyl chloride hose buried six inches deep, connected with insert fittings and double back tubing secured with tubing ties. Spaghetti tubing with bug caps connects additional emitters, and the tubing is secured with staples buried three inches deep. A flush valve is installed at the end of all lines to facilitate system maintenance.
DOUBLE BACK TUBING W/ TUBING TIE INSERT FITTING ROOT BALL BUG CAP STAPLE SPAGHETTI TUBING 1 2 GPM EMITTERS (2 PER TREE) FLEXIBLE PVC HOSE, BURY 6" DEEP IN LINE EMITTER TUBING 2/ EMITTERS SPACED AT 18", 4' DIA CIRCLE (12 LINEAL FEED. BURY 3" STAPLE, TYP. FLUSH VALVE AT THE END OF ALL LINES
