L-PGFRD — In-Plane Brace

Landscape · L-PGFRD

In-Plane Brace

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: LO-S6.0.2
Discipline: Landscape

Materials

Elements

Beams Bracing Columns Connections / Plates

Connections

Bracing Connection Gusset Plate Welded Connection

Text on the drawing

MIN 1/2" BRACE W.P. WIND GIRT 1/2" GUSSET PLATE, CENTERED ON POST IN-PLANE BRACE 3/16 1" MIN 3/16 1" MIN 3/16 1" MIN 3/16 1" MIN 3/16 3/16 MAX 1" 4" TYP 3/4" MIN MAX 2" MECH SCREEN POST TYP WIND GIRT TO ANGLE, SEE / 9 LO S6.0.2 1" = 1'-0" 5
