An underground flush valve connects to a threaded water supply manifold enclosed inside a six-inch round valve box set flush with the surrounding grade. Teflon tape is applied to all threaded manifold connections to prevent leaks. The entire assembly rests upon a compacted gravel base inside the protective box enclosure.
LEGEND 6" ROUND VALVE BOX 1 NOTES: USE TEFLON TAPE ON ALL THREADED MANIFOLD FINISH GRADE 1 2 5 4 3 9" 2
